Simu memory built-in timer AC for roller shutters

Simu memory built-in timer is easy to set without difficult menus. Press the button when you want to open and close the roller shutter every day and record this action. You always need one timer per Motor. The Simu memory timer can be used for all wired motors powered by 230 V, 4-wire (brown, black, blue and yellow/green wire).

- Wired timer
- suitable for all corded tubular motors (with brown and black wire)
- 3 buttons (up-stop-down)
- automatic function, repetition of recorded action every 24 hours
- memory function to record each action (long press)
- easy to set up, no difficult menus
- feedback on LED (LED on = Memory active / LED off = Memory inactive)
- white colour
- supply voltage 230 AC / 50 Hz
- switching current 3 A / 230 V AC
- reserve power supply (in case of power failure) 3 hours
- protection class IP20
- dimensions: 80x80x42 mm
- operating temperature: 0 C to 60 C
- Supplied without surface-mounted box (item 3660)
