Geba Cody Light HF 1/1 control cabinet

Geba Cody Light HF control box with relay NC/NO suitable for wired 4-code keypad, garage or industrial door control

- power supply 20-28 VDC or 230 VAC
- relay with NC/NO contact, maximum 5 Ampere
- connection option for antenna module
- with code keyboard a maximum of 4 codes

Setting a code in the Cosy control box
Four codes can be programmed into the memory. There is a block in the control box with four dip switches, each dip switch being a memory location for a code.
To set a new code, move the corresponding dipswitch upwards to the ON position. Then enter the desired four- or five-digit code via the keypad and confirm it with the keystroke. Then return the dipswitch to its original position. Test the entered code to make sure everything works correctly.
A previously programmed code at that memory location will be overwritten in the process. Repeat these steps for every other memory location (dipswitch).
