GMF Unwind protection FV 200

A roll-off protection functions like a normal bearing, on the other side of the roller shutter shaft than where the tube motor is mounted. If something in or on the tube motor fails, the Roller shutter will unwind at high speed, the roll-off protection intervenes and will block the Axle/Shaft, bringing the Roller shutter to a stop.

- maximum torque 2098 Nm
- blocking torque 9141 Nm
- torque (rpm) 12 rpm
- shaft diameter Ø 65 mm
- fixing hole spacing 300 mm
- weight 20 kg

This roll-off safety device FV 200 has been tested and inspected by the TÜV SÜD industry service and received the corresponding certification. They thus comply with European standards DIN EN 12604 / DIN EN 12605
(Issued Aug. 2000 ) and GS - BE - 04 (Issued Jan. 2001).
The roll-off safety guards have a damping system that considerably reduces the catching moment.
considerably.
