Somfy Sunea 50 io tubular motor for awnings
Somfy Sunea 50 io tubular motor, this motor is the perfect choice for all your awnings, whether standard screens or cassette awnings. With an integrated Somfy io receiver, this Motor offers advanced functionality and convenience.
What makes the Sunea 50 io so special? First of all, the automatic setting of the upper end point. This means you never have to worry about your awning closing imperfectly. Thanks to this feature, the upper end point is automatically corrected, keeping the fabric perfectly taut (fabric stretch compensation). Not only does this provide an aesthetically pleasing appearance, but it also reduces the load on the Motor and ensures quick power shutdown.
With the Somfy Sunea 50 io tubular motor, you are assured of both functionality and ease of use. Choose the best motor for your blinds and enjoy hassle-free comfort and reliable performance.
- Supplied without motor support and adapter set
- Tubular motor 230 V/50 Hz with integrated receiver.
- Reception range: 20 metres through 2 concrete walls.
- Choice between automatic or manual adjustment of the upper end point.
- The tubular motor can be operated with up to 9 1-way remote control units.
- The tubular motor can be operated with an infinite number of 2-way remote controls.
- Perfect closure of the awning thanks to fabric stretch compensation.
- Simple wireless adjustment using 1-way remote control.
- Adjustable automatic intermediate position possible.
- Back impulse: re-tension the fabric after each lowering movement.
- Supplied as standard with a white 3-wire (VVF) cable, length 5 m.
- Not suitable for continuous use and in combination with free-running systems (ABS).
- Operating time limited to 3 min.
- Quick mounting due to unique clip system.
- Not applicable with relay boxes, standard switches and standard controllers.
- Suitable for pipe with a minimum diameter of Ø 50 mm.
- Available in strengths from 6 to 50 Nm.
- Available in 12 and 17 rpm, depending on type of tubular motor.
Somfy Sunea 50 io tube motor is available in the following models
- Sunea io 6/17 (6 Nm / 17 rpm)
- Sunea io 10/17 (10 Nm / 17 rpm)
- Sunea io 15/17 (15 Nm / 17 rpm)
- Sunea io 20/17 (20 Nm / 17 rpm)
- Sunea io 25/17 (25 Nm / 17 rpm)
- Sunea io 30/17 (30 Nm / 17 rpm)
- Sunea io 35/17 (35 Nm / 17 rpm)
- Sunea io 40/17 (40 Nm / 17 rpm)
- Sunea io 50/12 (50 Nm / 12 rpm)
io-homecontrol® - the intelligent solution for maximum home comfort
io-homecontrol® controls the entire house, i.e. not only Roller shutters, blinds and garage doors but also the front door, skylights, windows, heating, lighting and ventilation. The 2-way radio technology informs the user, is operationally reliable and becomes the new standard on the market.
Somfy io-homecontrol® tubular motors
These motors have all the advantages of existing RTS motors + the benefits offered by io-homecontrol. An extensive range of motors will be available in 2017. These motors can be controlled by any io-homecontrol® 1-way or 2-way control. We recommend programming a local control (1-way) per motor. On the 2-way remote controls or in the app, the consumer receives feedback on whether the requested command was executed or other information that makes it easy for him to understand the operation.
Frequency and safety
2-way io-homecontrol® products can communicate on 3 different frequencies between 868 and 870 MHz. If the frequency used is not free, it is automatically switched to another frequency. The 1-way products only communicate on the 868 MHz frequency. Power failure does not affect stored data.
Flexibility
The 1-way remote controls are designed to control one Motor. The 2-way controls are group or central controls where the consumer receives feedback via an LED, via pictograms, via text or via sound. Sun and wind sensors operate the products automatically. Automatic operation can easily be blocked using the Smoove 1 A/M io, a Situo 5 VAR A/M io or in the app.
