T3.5 tubular motor for screens and roller shutters 12V / 24V
147,95 Incl. tax
Add to cart
T3.5 tubular motor for screens and roller shutters 12V / 24V
Simu

T3.5 tubular motor for screens and roller shutters 12V / 24V

The Simu T3.5 is controlled by a Switch. Motor has a speed of 10 to 25 rpm. Can be used for screens and roller shutters. The adjustment is adjustable with pivot pins. In strengths from 3 to 13 Nm. Read more.

147,95 Incl. tax
In stock
Je hebt nog 00:00:00 uur om je bestelling af te ronden.
  • Affiliated to Home shopping guarantee
  • Fast delivery Delivery within 2 working days
  • Free shipping when spending €100 (in NL)

Product description

Tubular motor for screens and roller shutters

- Motor support and adapter set not included in delivery
- power supply 12 or 24 V DC
- available in 3, 6 or 10 Nm
- speed 23 rpm at 3 Nm, 18 rpm at 6 Nm, 12 rpm at 10 Nm
- adjustment by means of countersunk pins.
- Applicable with relay boxes, standard switches and standard controllers.
- roller shutter motor fits into a tube with a minimum inner diameter of Ø 40 mm.
- final adjustment capacity: 40 revolutions (± 8°).
- roller shutter motor supplied as standard with a 2-wire white cable, length 2.5 m.
- accessories Somfy LT40 tubular motors or Simu T3.5
- not suitable for continuous use.

Specifications

Article number
4989
EAN Code
7432257897851
SKU
2006973
Motor series
Simu T3.5
Cable
2.5 metres, white, 0.75 mm2
Supply voltage
12 or 24 V DC
Maximum duration
10 cycles per day
Protection class
IP44
Ambient temperature
-10 °C to 40 °C and exceptionally -20 °C to 60 °C
Thermal protection
4 minutes
Revolutions
10, 16 & 30 rpm
Capacity final adjustment
40 revolutions
Emergency manual

Recently viewed

Specifications

Article number
4989
EAN Code
7432257897851
SKU
2006973
Motor series
Simu T3.5
Cable
2.5 metres, white, 0.75 mm2
Supply voltage
12 or 24 V DC
Maximum duration
10 cycles per day
Protection class
IP44
Ambient temperature
-10 °C to 40 °C and exceptionally -20 °C to 60 °C
Thermal protection
4 minutes
Revolutions
10, 16 & 30 rpm
Capacity final adjustment
40 revolutions
Emergency manual
