The Simu T8S can be operated using a Switch or control box. Tubular motor for security roller shutters and roller grilles. The adjustment is very precise with pivot pins. Available in strengths from 130 to 300 Nm. Read more.
- Supplied without motor support and adapter set
- Accessories Simu T8
- adjustment on motor head
- final adjustment capacity is 17 revolutions
- integrated electromagnetic brake
- integrated thermal protection
- maximum use 10 cycles per 24 hours
- fits into a tube with a minimum inside diameter of Ø 101.6 x 3.6 mm
- progressive limit switch
- supplied as standard with a 4-wire white cable, length 2.5 m
- applicable with relay boxes, standard switches and standard controllers
- speed 8 rpm
- power supply 230 V/50 Hz
