Article number
3254
EAN Code
7432257389394
SKU
TGS10000000/N
Motor series
Private label TTGO TG S
Cable
white 4-wire (VVF) cable, length 3 m.
Supply voltage
230 V - 50 Hz
Maximum duration
10 cycles per day
Protection class
IP44
Ambient temperature
-10 °C to 40 °C and exceptionally -20 °C to 60 °C
Thermal protection
4 minutes
Revolutions
14 rpm
Capacity final adjustment
46 revolutions
Emergency manual
