Elero VariEco M tubular motor for Roller shutters or Screens

Elero VariEco is a wired tubular motor with a mechanical end adjustment that can be easily controlled via a Switch or effortlessly integrated into a home automation system with external control modules. Adapter plate allows you to reuse the already installed motor support of an old Elero T9.

- Supplied without motor support and adapter set
- tubular motor 230 V/50 Hz
- available with a speed of 14 and 23 rpm
- available in 7 to 50 Nm
- successor of Elero T9 tubular motor (include adapter plate)
- precise mechanical adjustment
- fits tubes with a minimum inner diameter of 50 mm
- final adjustment capacity 35 rpm
- supplied as standard with a white 4-wire (VVF) cable, length 2 metres
- not suitable for continuous use

download the manual for the Elero VarioEco tubular motor here

Type Elero VariEco M tubular motor
- VariEco M7/23 - 7 Nm - 23 rpm - length 537 mm - 140 Watt
- VariEco M10 - 10 Nm - 14 rpm - length 477 mm - 140 Watt
- VariEco M12/23 - 12 Nm - 23 rpm - length 537 mm - 200 Watt
- VariEco M20 - 20 Nm - 14 rpm - length 537 mm - 200 Watt
- VariEco M30 - 30 Nm - 14 rpm - length 527 mm - 200 Watt
- VariEco M40 - 40 Nm - 14 rpm - length 557 mm - 270 Watt
- VariEco M50 - 50 Nm - 14 rpm - length 557 mm - 300 Watt
